1. Notifier Am 6000

Notifier's range of advanced addresable fire alarm control panels combine unrivalled robustness with class leading functionality and ease of use. A Notifier system is capable of not only monitoring its own performance but adapting to the changing environment within different areas of a building. This intelligent approach to fire detection has resulted in a range of stable, fault-tolerant systems which provide uninterrupted protection whilst practically eliminating the potential for unwanted false alarms.

4 loop modular fire detection control panel for the management of addressable type systems, expandible through 4 loop modules, equipped with own microprocessor, up to 16 loops. Each loop allows the connection of 99 detectors and 99 modules.

The control panel allows to manage separate gas detection system, thanks to a special interface module, the display must be on a separate remote terminal for technical alarms only. Output sounder controlled, relay output for general alarm and fault. Two serial outputs in standard version with two optional through additional card. Standard outputs for 24 terminals and PCs for download/upload programming. Optional outputs for Ethernet (TCP / IP) connection and USB output for PC or printer, or output for connection to RS232/485 NOTE-FIRE-NET.

Graphic display with 16 rows by 40 columns. Programmable text 32 characters each point and 32 characters each zone. 150 geographical zones and 400 groups with logical operators (AND, OR, DEL, etc.). 999 events archive. Auto programming of the loop with double address recognition.

Notifier Am 6000

Signal for maintenance requirements for the detectors. CPD Certificate according to EN 54 parts 2 and 4. Power supply 230VAC.

Standard Power Supply 4A. 1A at 24VDC auxiliary power. 12VDC charging of two batteries 17Ah.

Dimensions: 535mm x 435mm x 200mm.
